The Mitsubishi F800E VFD (Model FR-F840-00250-E3N6) is a versatile 15 HP, 460V Variable Frequency Drive designed for applications requiring precise variable torque control. With a rated output of 25A at 460V, this drive is suitable for industrial equipment such as fans, pumps, and HVAC systems. Designed with three-phase input/output and UL Type 1 enclosure, the F800E VFD integrates advanced communication protocols like Modbus TCP/IP and CC-Link IE, ensuring seamless connectivity with modern industrial automation systems. Backed by a 1-year warranty, this VFD is engineered for efficiency, connectivity, and durable performance.

  • Features and Benefits:
    • Horsepower: Rated at 15 HP with 110% and 120% overload capability, ideal for heavy-duty applications.
    • Voltage Compatibility: 460V input/output, standard for industrial systems.
    • Variable Torque: Provides efficient control for variable load applications.
    • Three-Phase Input/Output: Enables high-efficiency motor operation.
    • Communication Protocols: Includes Modbus TCP/IP and CC-Link IE for integrated automation.

Product Specifications

The Mitsubishi F800E VFD (FR-F840-00250-E3N6) is a powerful 15 HP, 460V AC drive, optimized for variable torque applications. It supports modern industrial communication protocols, offering reliable and flexible motor control in complex industrial setups.

Applications and Uses

Ideal for HVAC systems, fans, pumps, and other variable torque applications, this VFD provides efficient motor control and integrates with industrial automation systems for smooth, reliable operation.

Key Features and Benefits

15 HP Capacity: Supports heavy-duty industrial applications with up to 120% overload capacity.

Variable Torque: Optimized for variable load applications, ensuring efficient motor performance.

Three-Phase Input/Output: Standard configuration for industrial motor control.

Advanced Connectivity: Modbus TCP/IP and CC-Link IE protocols for seamless system integration.

UL Type 1 Enclosure: Suitable for safe indoor installations in controlled environments.

Installation and Maintenance Guidelines

Install the F800E VFD in a well-ventilated indoor area suited for UL Type 1 equipment. Follow grounding and setup instructions as per the user manual. Maintenance includes inspecting connections and cleaning dust buildup every 6 months, with an annual diagnostic check to maintain reliable performance.

Warranty and Support

The Mitsubishi F800E VFD includes a 1-year warranty covering defects in materials and workmanship. Support is available for installation, troubleshooting, and maintenance inquiries.

View full details

In-Depth Product Information and Specifications for Mitsubishi F800E VFD - 15 HP, 460V, 3-Phase, Variable Torque | Model FR-F840-00250-E3N6

Efficiency Comparison Chart

Applications and Recommended Use Cases

This variable frequency drive controls motor speed and torque by varying the frequency and voltage supplied to the motor on a 3-phase system, commonly used for pump and fan speed control, conveyor speed regulation, and other applications where matching motor speed to load cuts energy use and mechanical wear.\nSized for motors up to 15 HP.\nIts variable-torque rating fits centrifugal pump and fan loads well, where torque demand falls off at lower speeds, letting the drive deliver strong energy savings under partial-load operation.

Energy Cost Savings Over Time

Technical Specifications Breakdown

Motor Horsepower Rating: 15 HP\nInput Phase: 3-Phase\nOutput Phase: 3-Phase\nVoltage: 460V\nTorque Rating: Variable Torque

Maintenance Schedule and Requirements

Inspect Connections - Every 6 Months

Check all electrical connections for tightness and inspect for wear to ensure safe, continuous operation.

Dust Cleaning - Every 6 Months

Remove dust buildup from vents and surfaces to maintain optimal airflow and cooling efficiency.

Performance Check - Every 12 Months

Conduct a full diagnostic test to ensure optimal performance. Check for unusual sounds or vibrations indicating potential issues.
